TaurusReadWriteSwitcher

class TaurusReadWriteSwitcher(parent=None, designMode=False, readWClass=None, writeWClass=None, enterEditTriggers=None, exitEditTriggers=None)

This is a base class for creating widgets that can switch beetween read and write mode by combining a Taurus widget for reading and a Taurus Widget for writing.

For example, if you want to combine a TaurusLabel with a TaurusValueLineEdit, you can implement it as follows:

class MyRWSwitcher(TaurusReadWriteSwitcher):
    readWClass = TaurusLabel
    writeWClass = TaurusValueLineEdit

Alternatively, you can instantiate the TaurusReadWriteSwitcher class directly and pass the read and write classes to the constructor:

w = TaurusReadWriteSwitcher(readWClass=TaurusLabel,
                            writeWClass=TaurusValueLineEdit)

Or you can even set the read and write widgets (instead of classes) after instantiation:

w = TaurusReadWriteSwitcher()
a = TaurusLabel()
b = TaurusValueLineEdit()
w.setReadWidget(a)
w.setWriteWidget(b)

TaurusReadWriteSwitcher will normally show the read widget by default, but it will allow to switch to “edit mode” (where the write widget is shown instead). Enetering and exiting the edit mode is controlled by “triggers”. Triggers can be key presses, QEvents or signals.

The default implementation sets pressing F2 or doubleclicking the read widget as the triggers for entering edit mode, and pressing Escape, losing the focus or applying the value on the write widget as the triggers for leaving the edit mode. This can be customized by changing enterEditTriggers and exitEditTriggers class members or by passing enterEditTriggers and exitEditTriggers keyword parameters to the constructor of TaurusReadWriteSwitcher:

• enterEditTriggers is a tuple containing one or more of the following:

  • key shortcut (either a Qt.Qt.Key or a QKeySequence)

  • event type on the read widget (a Qt.QEvent.Type)

  • signal from the read widget (a str representing a Signal signature)

• exitEditTriggers is a tuple containing one or more of the following:

  • key shortcut (either a Qt.Qt.Key or a QKeySequence)

  • event type on the write widget (a Qt.QEvent.Type)

  • signal from the write widget (a str representing a Signal signature)

#@todo: check integration with designer

Import from taurus.qt.qtgui.compact as:

from taurus.qt.qtgui.compact import TaurusReadWriteSwitcher

enterEdit(*args, **kwargs)

Slot for entering Edit mode

Note

args and kwargs are ignored

enterEditTriggers = (16777265, 4)

eventFilter(obj, event)

reimplemented to intercept events from the read and write widgets

exitEdit(*args, **kwargs)

Slot for entering Edit mode

Note

args and kwargs are ignored

exitEditTriggers = (16777216, 9, 'applied')

classmethod getQtDesignerPluginInfo()

Returns pertinent information in order to be able to build a valid QtDesigner widget plugin.

The dictionary returned by this method should contain at least the following keys and values:

• ‘module’ : a string representing the full python module name (ex.: ‘taurus.qt.qtgui.base’)

• ‘icon’ : a string representing valid resource icon (ex.: ‘designer:combobox.png’)

• ‘container’a bool telling if this widget is a container widget or

  not.

This default implementation returns the following dictionary:

{ 'group'     : 'Taurus [Unclassified]',
  'icon'      : 'logos:taurus.png',
  'container' : False }

Returns:

a map with pertinent designer information

Return type:

dict

model

Returns the model name for this component.

Parameters:

key (object) – the model key. Defaults to first element of .modelKeys

Returns:

the model name.

Return type:

str

readWClass = None

setModel(model, **kwargs)

This implementation propagates the model to the read and write widgets.You may reimplement it to do things like passing different models to each.

setReadWidget(widget)

set the read Widget to be used. You can reimplement this method to tweak the read widget.

Parameters:

widget (QWidget) – This should be Taurus widget

setWriteWidget(widget)

set the write Widget to be used You can reimplement this method to tweak the write widget.

Parameters:

widget (Qt.QWidget) – This should be Taurus widget (typically a TaurusBaseWritableWidget)

writeWClass = None
