`QGroupWidget`

class QGroupWidget(parent=None, designMode=False)[source]

An expandable/collapsible composite widget

Import from taurus.qt.qtgui.container as:

from taurus.qt.qtgui.container import QGroupWidget

DefaultContentStyle = {'border_color': 'rgb(0, 85, 227)', 'border_radius': '5px', 'start_color': 'rgb(224, 224, 224)', 'stop_color': 'rgb(255, 255, 255)'}

DefaultContentVisible = True

DefaultTitleBarHeight = 16

DefaultTitleBarStyle = {'border_radius': '5px', 'font_color': 'white', 'start_color': 'rgb(60, 150, 255)', 'stop_color': 'rgb(0, 65, 200)'}

DefaultTitleBarVisible = True

collapseButton()[source]

Returns the collapse button widget

Returns:: the collapse button widget
Return type:: Qt.QToolButton

content()[source]

Returns the contents widget

Returns:: the content widget
Return type:: Qt.QFrame

contentStyle: The style must be a json dictionary

contentVisible

This property contains the widget’s content’s visibility

Access functions:

isContentVisible()

setContentVisible()

resetContentVisible()

getContentStyle()[source]

Returns this widget’s content style

Returns:: this widget’s content style
Return type:: dict

getContentStyleStr()[source]

Returns this widget’s content style

Returns:: this widget’s content style
Return type:: dict

classmethod getQtDesignerPluginInfo()[source]

getTitle()[source]

Returns this widget’s title

Returns:: this widget’s title
Return type:: str

getTitleHeight()[source]

Returns this widget’s title height

Returns:: this widget’s title height
Return type:: bool

getTitleIcon()[source]

Returns this widget’s title icon

Returns:: this widget’s title icon
Return type:: Qt.QIcon

getTitleStyle()[source]

Returns this widget’s title style

Returns:: this widget’s title style
Return type:: dict

getTitleStyleStr()[source]

Returns this widget’s title style

Returns:: this widget’s title style
Return type:: dict

isContentVisible()[source]

Returns this widget’s contents visibility

Returns:: this widget’s contents visibility
Return type:: bool

isTitleVisible()[source]

Returns this widget’s title visibility

Returns:: this widget’s title visibility
Return type:: bool

resetContentStyle()[source]: Resets this widget’s content style

resetContentStyleStr()[source]: Resets this widget’s content style

resetContentVisible()[source]: Resets this widget’s contents visibility

resetTitleHeight()[source]: Resets this widget’s title height

resetTitleStyle()[source]: Resets this widget’s title style

resetTitleStyleStr()[source]: Resets this widget’s title style

resetTitleVisible()[source]: Resets this widget’s title visibility

setContentStyle(style_map)[source]

Sets this widget’s content style Used key/values for style_map: - ‘start_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘stop_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’)

Parameters:: style_map (dict) – the new widget content style

setContentStyleStr(style_map)[source]

Sets this widget’s content style Used key/values for style_map: - ‘start_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘stop_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’)

Parameters:: style_map (dict) – the new widget content style

setContentVisible(show)[source]

Sets this widget’s contents visibility

Parameters:: show (bool) – the new widget contents visibility

setTitle(title)[source]

Sets this widget’s title

Parameters:: title (str) – the new widget title

setTitleHeight(h)[source]

Sets this widget’s title height

Parameters:: icon (bool) – the new widget title height

setTitleIcon(icon)[source]

Sets this widget’s title icon

Parameters:: icon (Qt.QIcon) – the new widget title icon

setTitleStyle(style_map)[source]

Sets this widget’s title style Used key/values for style_map: - ‘start_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘stop_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘font_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘border_radius’: radius (Ex.: ‘5px’, ‘5px,2px’)

Parameters:: style_map (dict) – the new widget title style

setTitleStyleStr(style_map)[source]

Sets this widget’s title style Used key/values for style_map: - ‘start_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘stop_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘font_color’ : brush (Ex.: ‘#E0E0E0’, ‘rgb(0,0,0)’, ‘white’) - ‘border_radius’: radius (Ex.: ‘5px’, ‘5px,2px’)

Parameters:: style_map (dict) – the new widget title style

setTitleVisible(show)[source]

Sets this widget’s title visibility

Parameters:: icon (bool) – the new widget title visibility

switchContentVisible()[source]: Switches this widget’s contents visibility

title

This property contains the widget’s title

Access functions:

getTitle()

setTitle()

titleBar()[source]

Returns the title bar widget

Returns:: the title bar widget
Return type:: Qt.QFrame

titleButton()[source]

Returns the title button widget

Returns:: the title button widget
Return type:: Qt.QToolButton

titleHeight

This property contains the widget’s title height

Access functions:

getTitleHeight()

setTitleHeight()

resetTitleHeight()

titleIcon

This property contains the widget’s title icon

Access functions:

getTitleIcon()

setTitleIcon()

titleStyle: The style must be a json dictionary

titleVisible

This property contains the widget’s title visibility

Access functions:

isTitleVisible()

setTitleVisible()
