TaurusWidget

Inheritance diagram of TaurusWidget
class TaurusWidget(parent=None, designMode=False)[source]

This is a Qt.QWidget that additionally accepts a model property. This type of taurus container classes are specially useful if you define a parent taurus model to them and set all contained taurus widgets to use parent model. Example:

from taurus.qt.qtgui.container import TaurusWidget
from taurus.qt.qtgui.display import TaurusLabel

widget = TaurusWidget()
layout = Qt.QVBoxLayout()
widget.setLayout(layout)
widget.model = 'sys/database/2'
stateWidget = TaurusLabel()
layout.addWidget(stateWidget)
stateWidget.model = 'sys/database/2/state'

Import from taurus.qt.qtgui.container as:

from taurus.qt.qtgui.container import TaurusWidget
applyPendingChanges()[source]
classmethod getQtDesignerPluginInfo()[source]

Returns pertinent information in order to be able to build a valid QtDesigner widget plugin.

The dictionary returned by this method should contain at least the following keys and values:

  • ‘module’ : a string representing the full python module name (ex.: ‘taurus.qt.qtgui.base’)

  • ‘icon’ : a string representing valid resource icon (ex.: ‘designer:combobox.png’)

  • ‘container’a bool telling if this widget is a container widget or

    not.

This default implementation returns the following dictionary:

{ 'group'     : 'Taurus [Unclassified]',
  'icon'      : 'logos:taurus.png',
  'container' : False }
Returns

a map with pertinent designer information

Return type

dict

model

Returns the model name for this component.

Parameters

key (object) – the model key. Defaults to first element of .modelKeys

Returns

the model name.

Return type

str

modifiableByUser

whether the user can change the contents of the widget

Returns

True if the user is allowed to modify the look&feel

Return type

bool

resetPendingChanges()[source]
showQuality

Returns if showing the quality as a background color

Returns

True if showing the quality or False otherwise

Return type

bool

useParentModel

(deprecated))
