TaurusCurveDialog

Inheritance diagram of TaurusCurveDialog
class TaurusCurveDialog(parent=None, designMode=False, toolbar=True, **kwargs)[source]

A taurus dialog for showing 1D data. It behaves as a regular guiqwt.plot.CurveDialog but it also offers the expected Taurus interface (e.g. setting models, save/apply configs, drag&drops,…)

See also

TaurusCurveWidget

Import from taurus.qt.qtgui.extra_guiqwt as:

from taurus.qt.qtgui.extra_guiqwt import TaurusCurveDialog
addModels(modelNames)[source]

Creates TaurusCurveItems (one for each model in modelNames) and attaches them to the plot.

Note

you can also add curves using add_items(). addModels() is only a more Taurus-oriented interface. add_items() gives you more control.

Parameters

modelNames (sequence<str> or str) – the names of the models to be plotted. For convenience, string is also accepted (instead of a sequence of strings), in which case the string will be internally converted to a sequence by splitting it on whitespace and commas. Each model can optionally be composed of two parts, separated by “|” indicating X and Y components for the curve. If only one part is given, it is used for Y and X is automatically generated as an index.

See also

add_item()

getModel()[source]

reimplemented from TaurusBaseWidget

getModelClass()[source]

reimplemented from TaurusBaseWidget

classmethod getQtDesignerPluginInfo()[source]

reimplemented from TaurusBaseWidget

keyPressEvent(self, QKeyEvent)[source]
model

reimplemented from TaurusBaseWidget

modelChanged
modifiableByUser

whether the user can change the contents of the widget

Returns

True if the user is allowed to modify the look&feel

Return type

bool

setModel(modelNames)[source]

Removes current TaurusCurveItems and adds new ones.

Parameters

modelNames (sequence<str> or str) – the names of the models to be plotted. For convenience, a string is also accepted (instead of a sequence of strings), in which case the string will be internally converted to a sequence by splitting it on whitespace and commas. Each model can optionally be composed of two parts, separated by “|” indicating X and Y components for the curve. If only one part is given, it is used for Y and X is automatically generated as an index.

See also

addModels()

setModifiableByUser(modifiable)[source]

reimplemented from TaurusBaseWidget
