QDictionaryEditor

Inheritance diagram of QDictionaryEditor
class QDictionaryEditor(parent=None, designMode=None, title=None)[source]

Import from taurus.qt.qtgui.table as:

from taurus.qt.qtgui.table import QDictionaryEditor
getModelClass(**kwargs)[source]

Return the class object for the widget. Default behavior is to do a ‘best effort’ to determine which model type corresponds to the current model name. Overwrite as necessary.

Parameters:

key (object) – the model key. Defaults to first element of .modelKeys

Returns:

The class object corresponding to the type of Taurus model this widget handles or None if no valid class is found.

Return type:

class TaurusModel or None

getValues()[source]
save()[source]
setModel(model, **kwargs)[source]

Sets/unsets the model name for the given key. If key is MLIST, a model is set for each name in the model sequence, new model keys are automatically added to the object’s modelList attribute and the corresponding models are attached using those keys. The new keys are of the form (MLIST, i) where i is the index of the corresponding model name in the model sequence.

Parameters:
  • model (str (or sequence of str if key is MLIST)) – the new model name. If key is MLIST, model is expected to be a sequence of model names.

  • key (object) – the model key. Defaults to first element of .modelKeys

updateStyle()[source]

Updates the widget style. Default implementation just calls QWidget.update()

Override when necessary.
