TangoAttribute

class TangoAttribute(name='', parent=None, **kwargs)

Import from taurus.core.tango as:

from taurus.core.tango import TangoAttribute

addListener(listener)

Add a TaurusListener object in the listeners list. If it is the first element and Polling is enabled starts the polling mechanism. If the listener is already registered nothing happens.

property alarms

property calarms

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getAlarms instead

cleanUp()

The cleanUp. Default implementation does nothing Overwrite when necessary

property climits

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getRange instead

property cranges

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getRange + getAlarms + getWarnings instead

property cwarnings

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getAlarms instead

decode(attr_value)

Decodes a value that was received from PyTango into the expected representation

property description

property dev_alias

displayValue(**kwargs)

Deprecated since version 4.0.

encode(value)

Translates the given value into a tango compatible value according to the attribute data type.

Raises pint.DimensionalityError if value is a Quantity and it cannot be expressed in the units of the attribute set in the DB

property format

for backwards compat with taurus < 4

Deprecated since version 4.0.4: Use format_spec or precision instead

getAlarms(cache=True)

getAttributeInfoEx(cache=True)

getAttributeProxy()

Convenience method that creates and returns a PyTango.AttributeProxy object

getCAlarms(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getAlarms instead

getCLimits(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getRange instead

getCRanges(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use getRange + getAlarms + getWarnings instead

getCWarnings(**kwargs)

Deprecated since version 4.0: Use getWarnings instead

getConfig(**kwargs)

Returns the current configuration of the attribute.

Deprecated since version 4.0: Use self instead

getDescription(**kwargs)

Deprecated since version 4.0: Use .description instead

getDisplayUnit(**kwargs)

Deprecated since version 4.0: Use .rvalue.units instead

getDisplayValue(**kwargs)

Deprecated since version 4.0: Use getLabel instead

getDisplayWriteValue(**kwargs)

Deprecated since version 4.0.

getFormat(cache=True)

getLabel(cache=True)

getLimits(cache=True)

getMaxAlarm(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .alarms[1] instead

getMaxDim(cache=True)

getMaxDimX(**kwargs)

Deprecated since version 4.0: Use getMaxDim instead

getMaxDimY(**kwargs)

Deprecated since version 4.0: Use getMaxDim instead

getMaxValue(**kwargs)

Deprecated since version 4.0: Use getMaxRange instead

getMaxWarning(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .warnings[1] instead

getMinAlarm(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .alarms[0] instead

getMinValue(**kwargs)

Deprecated since version 4.0: Use getMinRange instead

getMinWarning(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .warnings[0] instead

getNewOperation(value)

getParam(**kwargs)

Get attributes of AttributeInfoEx (PyTango)

Deprecated since version 4.0: Use getAttributeInfoEx instead

getRange(cache=True)

getRanges(cache=True)

getShape(**kwargs)

Deprecated since version 4.0.

getStandardUnit(**kwargs)

Deprecated since version 4.0: Use .rvalue.units instead

getSubscriptionState()

getTangoWritable(cache=True)

like TaurusAttribute.isWritable(), but it returns a PyTango.AttrWriteType instead of a bool

getUnit(**kwargs)

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .rvalue.units instead

getWarnings(cache=True)

getWritable(**kwargs)

Deprecated since version 4.0: Use isWritable instead

isBoolean(inc_array=False)

isFloat(inc_array=False)

isImage(**kwargs)

Deprecated since version 4.0: Use self.data_format instead

isInformDeviceOfErrors(**kwargs)

Deprecated since version 4.0.

isInteger(inc_array=False)

isReadOnly(cache=True)

isReadWrite(cache=True)

isScalar(**kwargs)

Deprecated since version 4.0: Use self.data_format instead

isSpectrum(**kwargs)

Deprecated since version 4.0: Use self.data_format instead

isState()

returns whether the attribute of tango DevState type

isUsingEvents()

isWrite(cache=True)

property label

property max_alarm

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .alarms[1] instead

property max_warning

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .warnings[1] instead

property min_alarm

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .alarms[0] instead

property min_warning

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .warnings[0] instead

no_abs_change = 'Not specified'

no_archive_abs_change = 'Not specified'

no_archive_period = 'Not specified'

no_archive_rel_change = 'Not specified'

no_cfg_value = '-----'

no_delta_t = 'Not specified'

no_delta_val = 'Not specified'

no_description = 'No description'

no_display_unit = 'No display unit'

no_max_alarm = 'Not specified'

no_max_value = 'Not specified'

no_max_warning = 'Not specified'

no_min_alarm = 'Not specified'

no_min_value = 'Not specified'

no_min_warning = 'Not specified'

no_rel_change = 'Not specified'

no_standard_unit = 'No standard unit'

no_unit = 'No unit'

not_specified = 'Not specified'

poll(single=True, value=None, time=None, error=None)

Notify listeners when the attribute has been polled

push_event(event)

Method invoked by the PyTango layer when an event occurs. It propagates the event to listeners and delegates other tasks to specific handlers for different event types.

property range

read(cache=True)

Returns the current value of the attribute.

If cache is False it will force a read from the device and return its value. If cache is True, it will return the cached value. If cache is a number, it will return the cached value if it’s newer than the specified number (in ms). Otherwise, it will act as if cache is False. If no cached value is available and cache is not False, it will wait until the polling or an event fill the cache to return its value. If polling is disabled and the attribute doesn’t send events, it will act as if cache is False.

If there is an application and it’s starting, the cache validations are skipped and returns de cached value or None if the cache is empty.

Parameters:

cache (bool or float) – use cache value or make readout, eventually pass a cache’s expiration period in milliseconds

Returns:

attribute value

Return type:

TangoAttributeValue

removeListener(listener)

Remove a TaurusListener from the listeners list. If polling enabled and it is the last element the stop the polling timer. If the listener is not registered nothing happens.

setAlarms(*limits)

setConfigEx(config)

setDescription(**kwargs)

Deprecated since version 4.0: Use .description instead

setLabel(lbl)

setLimits(low, high)

setMaxAlarm(**kwargs)

Deprecated since version 4.0: Use .alarms instead

setMaxWarning(**kwargs)

Deprecated since version 4.0: Use .warnings instead

setMinAlarm(**kwargs)

Deprecated since version 4.0: Use .alarms instead

setMinWarning(**kwargs)

Deprecated since version 4.0: Use .warnings instead

setParam(**kwargs)

Set attributes of AttributeInfoEx (PyTango)

Deprecated since version 4.0: Use PyTango instead

setRange(*limits)

setWarnings(*limits)

subscribePendingEvents()

Execute delayed event subscription

property unit

for backwards compat with taurus < 4

Deprecated since version 4.0: Use .rvalue.units instead

property warnings

write(value, with_read=True)

Write the value in the Tango Device Attribute
