TaurusValue

class TaurusValue(parent=None, designMode=False, customWidgetMap=None)

Internal TaurusValue class

Warning

TaurusValue (and any derived class from it) should never be instantiated directly. It is designed to be instantiated by a TaurusForm class, since it breaks some conventions on the way it manages layouts of its parent model.

Import from taurus.qt.qtgui.panel as:

from taurus.qt.qtgui.panel import TaurusValue

addCustomWidgetToLayout(**kwargs)

Deprecated since version 4.6.5: Use item factories instead

addExtraWidgetToLayout()

addLabelWidgetToLayout()

addReadWidgetToLayout()

addUnitsWidgetToLayout()

addWriteWidgetToLayout()

allowWrite

applyConfig(configdict, **kwargs)

extending TaurusBaseWidget.applyConfig() to restore the subwidget’s classes

Parameters:

configdict (dict) –

See also

TaurusBaseWidget.applyConfig(), createConfig()

createConfig(allowUnpickable=False)

extending TaurusBaseWidget.createConfig() to store also the class names for subwidgets

Parameters:

alllowUnpickable (bool) –

Returns:

configurations (which can be loaded with applyConfig()).

Return type:

dict<str,object>

customWidget(**kwargs)

Returns the custom widget

Deprecated since version 4.6.5: Use item factories instead

customWidgetClassFactory(**kwargs)

Deprecated since version 4.6.5: Use item factories instead

extraWidget()

Returns the extra widget

extraWidgetClass

extraWidgetClassFactory(classID)

getAllowWrite()

getCustomWidgetClass(**kwargs)

Deprecated since version 4.6.5: Use item factories instead

getCustomWidgetMap(**kwargs)

Returns the map used to create custom widgets.

return:

a dictionary whose keys are device type strings (i.e. see PyTango.DeviceInfo) and whose values are widgets to be used

rtype:

dict<str,Qt.QWidget>

Deprecated since version 4.6.5: Use item factories instead

getDefaultCustomWidgetClass(**kwargs)

Deprecated since version 4.6.5: Use item factories instead

getDefaultExtraWidgetClass()

getDefaultLabelWidgetClass()

getDefaultReadWidgetClass(returnAll=False)

Returns the default class (or classes) to use as read widget for the current model.

Parameters:

returnAll (bool) – if True, the return value is a list of valid classes instead of just one class

Returns:

the default class to use for the read widget (or, if returnAll==True, a list of classes that can show the attribute ). If a list is returned, it will be loosely ordered by preference, being the first element always the default one.

Return type:

class or list<class>

getDefaultUnitsWidgetClass()

getDefaultWriteWidgetClass(returnAll=False)

Returns the default class (or classes) to use as write widget for the current model.

Parameters:

returnAll (bool) – if True, the return value is a list of valid classes instead of just one class

Returns:

the default class to use for the write widget (or, if returnAll==True, a list of classes that can show the attribute ). If a list is returned, it will be loosely ordered by preference, being the first element always the default one.

Return type:

class or list<class>

getExtraWidgetClass()

getLabelConfig()

getLabelWidgetClass()

getModelClass(**kwargs)

Return the class object for the widget. Default behavior is to do a ‘best effort’ to determine which model type corresponds to the current model name. Overwrite as necessary.

Parameters:

key (object) – the model key. Defaults to first element of .modelKeys

Returns:

The class object corresponding to the type of Taurus model this widget handles or None if no valid class is found.

Return type:

class TaurusModel or None

getPreferredRow()

classmethod getQtDesignerPluginInfo()

Returns pertinent information in order to be able to build a valid QtDesigner widget plugin.

The dictionary returned by this method should contain at least the following keys and values:

• ‘module’ : a string representing the full python module name (ex.: ‘taurus.qt.qtgui.base’)

• ‘icon’ : a string representing valid resource icon (ex.: ‘designer:combobox.png’)

• ‘container’a bool telling if this widget is a container widget or

  not.

This default implementation returns the following dictionary:

{ 'group'     : 'Taurus [Unclassified]',
  'icon'      : 'logos:taurus.png',
  'container' : False }

Returns:

a map with pertinent designer information

Return type:

dict

getReadWidgetClass()

getRow()

getSwitcherClass()

Returns the TaurusValue switcher class (used in compact mode). Override this method if you want to use a custom switcher in TaurusValue subclasses.

getUnitsWidgetClass()

getWriteWidgetClass()

handleEvent(evt_src, evt_type, evt_value)

Reimplemented from TaurusBaseWidget.handleEvent() to update subwidgets on config events

hasPendingOperations()

self.getPendingOperations will always return an empty list, but still self.hasPendingOperations will look at the writeWidget’s operations. If you want to ask the TaurusValue for its pending operations, call self.writeWidget().getPendingOperations()

isCompact()

isReadOnly()

Determines if this component is read-only or not in the sense that the user can interact with it. Default implementation returns True.

Override when necessary.

Returns:

whether or not this component is read-only

Return type:

bool

isValueChangedByUser()

labelConfig

labelWidget()

Returns the label widget

labelWidgetClass

labelWidgetClassFactory(classID)

minimumHeight(self) → int

model

Returns the model name for this component.

Parameters:

key (object) – the model key. Defaults to first element of .modelKeys

Returns:

the model name.

Return type:

str

modifiableByUser

whether the user can change the contents of the widget

Returns:

True if the user is allowed to modify the look&feel

Return type:

bool

onChangeLabelConfig()

onChangeReadWidget()

onChangeWriteWidget()

onSetFormatter()

Reimplemented to call onSetFormatter of the read widget (if provided)

parentModelChanged(parentmodel_name)

Invoked when the parent model changes

Parameters:

parentmodel_name (str) – the new name of the parent model

preferredRow

readWidget(followCompact=False)

Returns the read widget. If followCompact=True, and compact mode is used, it returns the switcher’s readWidget instead of the switcher itself.

readWidgetClass

readWidgetClassFactory(classID)

resetAllowWrite()

resetCustomWidgetClass(**kwargs)

Deprecated since version 4.6.5: Use item factories instead

resetExtraWidgetClass()

resetLabelConfig()

resetLabelWidgetClass()

resetPreferredRow()

resetReadWidgetClass()

resetUnitsWidgetClass()

resetWriteWidgetClass()

setAllowWrite(mode)

setCompact(compact)

setCustomWidgetClass(**kwargs)

substitutes the current widget by a new one. classID can be one of:

None, ‘Auto’, a TaurusWidget class name, or any class

Deprecated since version 4.6.5: Use item factories instead

setCustomWidgetMap(**kwargs)

Sets a map map for custom widgets.

param cwmap:

a dictionary whose keys are device class strings (see PyTango.DeviceInfo) and whose values are widget classes to be used

type cwmap:

dict<str,Qt.QWidget>

Deprecated since version 4.6.5: Use item factories instead

setDangerMessage(dangerMessage=None)

Sets the danger message when applying an operation. If dangerMessage is None, the apply operation is considered safe

Parameters:

dangerMessage (str or None) – the danger message. If None is given (default) the apply operation is considered safe

setExtraWidgetClass(classID)

substitutes the current widget by a new one. classID can be one of: None, ‘Auto’, a TaurusWidget class name, or any class

setForceDangerousOperations(yesno)

Forces/clears the dangerous operations

Parameters:

yesno (bool) – force or not the dangerous operations

setFormat(format)

Reimplemented to call setFormat of the read widget (if provided)

setLabelConfig(config)

Sets fragment configuration to the label widget.

Parameters:

config (str) – fragment

setLabelWidgetClass(classID)

substitutes the current widget by a new one. classID can be one of: None, ‘Auto’, a TaurusWidget class name, or any class

setMinimumHeight(self, minh: int)

setModel(model, **kwargs)

extending TaurusBaseWidget.setModel() to change the modelclass dynamically and to update the subwidgets

setParent(self, parent: Optional[QWidget])

setParent(self, parent: Optional[QWidget], f: Qt.WindowFlags | Qt.WindowType) → None

setPreferredRow(row)

setReadWidgetClass(classID)

substitutes the current widget by a new one. classID can be one of: None, ‘Auto’, a TaurusWidget class name, or any class

setUnitsWidgetClass(classID)

substitutes the current widget by a new one. classID can be one of: None, ‘Auto’, a TaurusWidget class name, or any class

setVisible(self, visible: bool)

setWriteWidgetClass(classID)

substitutes the current widget by a new one. classID can be one of: None, ‘Auto’, a TaurusWidget class name, or any class

unitsWidget()

Returns the units widget

unitsWidgetClass

unitsWidgetClassFactory(classID)

updateCustomWidget(**kwargs)

Deprecated since version 4.6.5: Use item factories instead

updateExtraWidget()

updateLabelWidget()

updatePendingOpsStyle()

This method should be reimplemented by derived classes that want to change their appearance depending whether there are pending operations or not

updateReadWidget()

updateUnitsWidget()

updateWriteWidget()

writeWidget(followCompact=False)

Returns the write widget. If followCompact=True, and compact mode is used, it returns the switcher’s writeWidget instead of None.

writeWidgetClass

writeWidgetClassFactory(classID, ignoreCompact=False)
